The A30plus is not just an upgrade — it is a fully optimized spray system designed for higher performance, greater efficiency, and improved usability.
Key Improvements in the A30plus:
-
Improved airflow and transfer efficiency
-
Finer and more consistent atomization
-
Expanded nozzle options
-
Full compatibility with all A30 air caps
These enhancements are built into the complete A30plus system design. As a result, the original A30 cannot achieve the same performance level — even when using similar nozzles or air caps.
1. What Makes the A30plus Perform Better?
1.1 Optimized Airflow & Atomization
The A30plus delivers:
-
Finer and more consistent particle distribution
-
Noticeably improved clearcoat leveling
-
Easier and faster setup
The retuned airflow system enhances atomization efficiency, resulting in smoother finishes and better material control.
1.2 Expanded Nozzle System
The A30plus offers additional nozzle configurations for broader applications, including:
-
Solvent and waterborne basecoats
-
Clearcoats
-
Spot repairs
-
Detailed and precision work
This flexibility allows painters to select the ideal setup for each job.
1.3 Full Support for Ti1, FX1 & CH Air Caps
The A30plus is fully compatible with:
Ti1 Air Cap
→ Enhanced airflow control
→ Greater adjustability
FX1 Air Cap
→ Balanced performance
→ Fast operating speed
→ High precision
CH Air Cap
→ Slightly wider fan pattern
→ Finer atomization
→ Higher transfer efficiency
⚠ Important:
The CH air cap achieves its full performance only when paired with the correct nozzle and used with the A30plus gun body.
2. Correct Nozzle × Air Cap Matching
Proper pairing is essential to unlock maximum performance.
CH Air Cap
→ Must be paired with the (1.0) Type C nozzle
→ Designed for CH’s fine atomization
→ Ensures maximum fan width and consistency
→ Easy to set up
FX1 Air Cap
→ Must be paired with the Type F nozzle
→ Faster fluid flow
→ Ideal for painters who prefer faster movement
→ Lower air consumption
Correct matching guarantees optimal spray pattern, efficiency, and finish quality.
3. Why the Original A30 Cannot Match A30plus Performance
The A30plus is a completely retuned system with:
-
Improved airflow dynamics
-
Enhanced atomization efficiency
-
Higher transfer efficiency
Because these upgrades are integrated into the gun body design itself, the previous A30 cannot reproduce the full performance of the A30plus — even with similar components.
4. A30plus Key Advantages
1. More consistent and even fan pattern
2. Finer atomization
3. Expanded nozzle options for wider applications
4. Improved transfer efficiency
5. Full compatibility with all A30 air caps
6. The original A30 cannot replace the full performance of the A30plus
